CE 19-175mm Hydraulic Torque Machine For Bolt Solution

CE 19-175mm Hydraulic Torque Machine For Bolt Solution
CE 19-175mm Hydraulic Torque Machine For Bolt Solution CE 19-175mm Hydraulic Torque Machine For Bolt Solution CE 19-175mm Hydraulic Torque Machine For Bolt Solution CE 19-175mm Hydraulic Torque Machine For Bolt Solution CE 19-175mm Hydraulic Torque Machine For Bolt Solution

Large Image :  CE 19-175mm Hydraulic Torque Machine For Bolt Solution Get Best Price

Product Details:
Place of Origin: China
Brand Name: PENAD
Certification: ISO, CE/TUV
Model Number: PDCT
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Packaging Details: Carton
Delivery Time: 3-4 working days
Supply Ability: 3000/SET/YEAR
Detailed Product Description
Material: Aluminium-Titanium Alloy Color: Red, Silver, Blue, Black
OEM: Available Brand: Penad
Model: PDCT Suitable Nut Size: 19-175mm
Origin: China
High Light:

175mm hydraulic torque machine

,

19mm hydraulic torque machine

,

bolt solution hydraulic torque machine

Hexagon cassette hydraulic torque gun manufacturer for mining , petroleum platform , power plant



 Hangzhou Penad machinery co.,ltd. specialized in hydraulic torque gun/wrench manufacturing for years, richful experience engineers, skilled workers, avanced machining equipments, we can provide you high quality product to your bolt solutions. exported to USA, UK, Australia, Canada, Spain, Denmark, Germany, Brazile, Chile, Singapore, Korea and India. gain confirmation and reputation. for steady quality and reasonable price.



Hexagon cassette hydraulic torque gun Characters:



The hydraulic torque gun, made of ultra-high strength aluminum-titanium alloy, thin design, double - acting, high speed and big corner, can be used for narrow space.

The hydraulic torque gun, high stength and acurrate, the accuracy can reach to ±3%, gain more and more customers confirmation and reputation. And the torque gun, the work head can be replaced, different size, more convenient and fast. save time and improve the work efficiency. used such as petroleum, chemical, power, mining and many other fields.





CE 19-175mm Hydraulic Torque Machine For Bolt Solution 0





Product Drawings:



CE 19-175mm Hydraulic Torque Machine For Bolt Solution 1



Technical Data:

SELECTION CHART OF PDCT SERIES ULTRO THIN HOLLOW HYDRAULIC WRENCH
MODEL 2PDCT 4PDCT 8PDCT 14PDCT 18PDCT 30PDCT 50PDCT
TORQUE(N.m) 232-2328 241-2414 585-5858 647-6474 1094-10941 1177-11774 1852-18521 2695-26958 488-41882 4459-44593 7081-70813
NUT SIZE(S) 19-55 60 34-65 70-80 41-95 100-105 50-117 65-130 110-155 160-175 105-225
POWER HEAD WEIGHT(KG) 0.9 0.9 1.7 1.7 3 3.1 4.6 6.5 10.4 10.4 35.5
WORKING HEAD WEIGHT(KG) 1.5 1.5 3.4 3.4 6.3 6.3 11.4 14.3 20.5 20.5 42
L 196 196 258 263 30 311 360 388 430 441 493
H1 126 129 163 173 192 201 225 264 303 315 328
H2 102 105 136 146 168 177 2045 231 272 285 295
W1 32 32 42 42 53 53 64 71 85 85 102
W2 51 51 66 66 83 83 99 109 131 131 160



How to choose the correct model:



The selection of hydraulic wrench is determined by bolt size, torque requirements and space range.

  1. Bolt size, firstly, need to confirm the specification of the bolt, metric or imperial, and the bolt size. If including many different size of nuts, we suggest choose different model of hydraulic torque wrench according to nuts size and torque force.
  2. The specification and strength grade of bolts are the most critical parameters of hydraulic torque wrench selection.
  3. Space position of bolts and nuts, if the space permitted, PDTA square drive hydraulic torque wrench and PDCT low profile hydraulic torque wrench are suitable, if the space is narrow, we suggest to adopt the PDCT series of wrench.
  4. 1 ) One model of hydraulic wrench can only solve several similar bolts, usually with 1 - 10 impact sockets;
    2 ) it is best for qualified manufacturers to use an electric pump with two wrench heads, and use it diagonally, which can improve efficiency and torque more accurately.
    3 ) hydraulic wrenches must be used by special personnel, kept by special personnel and often maintained, such as oil change and cleaning.





Application field:



Our hydraulic torque wrenches are wildely used in mining , wind power plant , petroleum , chemical and many other field



CE 19-175mm Hydraulic Torque Machine For Bolt Solution 2
